MOBMIX PRO 60 Mobile Concrete Batching Plant (Twin Shaft)
Twin Shaft Mixer (1000 Liters, 60M3/HR) | Control: PLC + HMI (SCADA Optional)
The Atlas MOBMIX PRO 60 Mobile Concrete Batching Plant combines high-capacity concrete production with full mobility. Delivering 60 m³ per hour, it brings stationary-grade twin-shaft mixing performance to sites that demand fast relocation, short setup times, and reliable on-site concrete supply....
Read More
High Output
Stationary-Quality Mix
True Mobility
MOBMIX PRO 45: Reliable Concrete Production On the Move
Key Features & Benefits
Engineered for Portability, Consistency, and Performance
60 m³/hr Production Capacity
The high capacity of this plant makes it ideal for high-volume concrete demands in infrastructure and RMC projects.
Twin Shaft Mixer (1500/1000 L)
Produces 1 m³ vibrated concrete per cycle; Ni-Hard bottom (16 mm) and side (12 mm) liners, cast-iron blades (600 HB), automatic grease pump, and hydraulic discharge.
Mobile Single-Chassis Construction
Aggregate bins, mixer, and control cabin mounted on a fabricated chassis for rapid setup and site relocation.
Smart PLC + HMI Automation
7" TFT touchscreen (HMI – EXOR / Delta) with recipe storage, data logging, USB backup, Ethernet remote access, and optional SCADA/Wi-Fi control.
Why Choose MOBMIX PRO 45 (Twin Shaft Mixer)
Built for dependable, low-maintenance operation, the MOBMIX PRO 45 ensures consistent batching accuracy, reduced downtime, and long-term reliability.
Stationary-Level Mix Quality
Twin-shaft mixing achieves uniform density and workability for all concrete types, including RCC and PQC.
Rapid Setup & Mobility
All assemblies are pre-wired and mounted for quick erection without a civil foundation.
Heavy-Duty Design for Continuous Use
PU-painted steel structure, ISI-grade motors, and Atlas quality gear units ensure durability in harsh environments.
Operator-Friendly Control
Fully Automatic and manual modes with recipe control and production logging make the plant easy to run and monitor.
Load-Cell Weighing System
Aggregates, cement, water, and admixtures are individually weighed for accurate, consistent mix ratios.
Components Breakdown
Each sub-system of the MOBMIX PRO 45 is engineered for accuracy, safety, and ease of transport.
- • Four bins (10 m³ each) with pneumatic discharge gates and a vibrator.
- • 5 mm MS construction; loading width 3.6 m; height 5.5 m.
Smart Design, Seamless Operation
Browse our range of products designed for exceptional performance and reliability.
CONNECT WITH US
Ready to Build? Let’s Talk!
Whether you’re expanding existing facilities or starting new projects, we’re here to help you achieve optimal results. Complete the form, and our engineers will provide a customized solution within 24 hours.
Frequently asked questions.
1. What type of projects is the MOBMIX PRO 60 best suited for?
+Perfect for large-scale RMC, airport runways, dams, and infrastructure projects requiring continuous on-site concrete supply.
