ATMIX PRO 45 T Stationary Concrete Batching Plant
Mixer: 750 Liters | Twin Shaft (0.75 m³/batch) | Control: PLC + HMI (SCADA Optional)
The Atlas ATMIX PRO 45 T Stationary Concrete Batching Plant delivers efficient, high-precision concrete production for medium-sized projects. With a rated capacity of 45 cubic meters per hour, it ensures consistent output, low maintenance, and long-term dependability for both infrastructure and commercial applications....
Read More
High Strength
Consistent Quality
Compact Reliability
ATMIX PRO 45 T: Precision Concrete for Every Project
Key Features & Benefits
Tailor-Made for Accuracy, Reliability, and Continuous Output
Optimized for Mid-Sized Projects
Rated at 45 m³/hr, the plant ensures steady concrete production for diverse construction needs without interruption.
Twin-Shaft Mixer (1125/750 L)
Produces 0.75 m³ per batch using wear-resistant Ni-Hard liners and cast-iron blades for long service life.
Advanced PLC + HMI Control
Siemens/B&R/Delta interface with SCADA-ready functionality for recipe storage and production tracking.
Efficient Four-Bin Feeding System
Four 10 m³ bins with pneumatically operated gates and load-cell-based proportioning for accurate aggregate feeding.
Why Choose ATMIX PRO 45 T
Built for dependable, low-maintenance operation, the ATMIX PRO 45 T ensures consistent batching accuracy, reduced downtime, and long-term operational reliability.
Reliable Mixing Cycle
0.75 m³ batches mixed in ~60 seconds with automatic grease lubrication and emergency manual discharge.
Quick Setup & Operator Comfort
Pre-wired units with insulated control cabins enable fast installation and easy plant management.
Durable, Heavy-Duty Construction
Rolled steel chassis, PU paint finish, and ISI-grade motors ensure corrosion resistance and mechanical stability.
Safety & Maintenance Ease
Guarded drives, emergency stops, and service platforms minimize risk and simplify regular upkeep.
Water & Additive Dosing
Load-cell-mounted hoppers ensure consistent mix ratios and moisture levels for durable, high-performance concrete.
Components Breakdown
Each module in the ATMIX PRO 45 T is engineered to deliver reliability, easy access, and consistent concrete quality.
- • Four bins (10 m³ each) with pneumatic discharge gates.
- • Constructed from 5 mm mild steel with smooth material flow.
- • Fitted with a vibrator for uniform discharge.
Smart Design, Seamless Operation
Browse our range of products designed for exceptional performance and reliability.
CONNECT WITH US
Ready to Build? Let’s Talk!
Whether you’re expanding existing facilities or starting new projects, we’re here to help you achieve optimal results. Complete the form, and our engineers will provide a customized solution within 24 hours.
Frequently asked questions.
1. What types of projects can the ATMIX PRO 45 T handle?
+Ideal for urban construction, precast manufacturing, road development, and infrastructure projects requiring medium-scale concrete output.
